Electric Power Light Truck

This is a new model electric light truck of New Longma. The 8T electric light truck has a very good power output whether driving at a low speed or climbing up a hill. The length, width and height of the vehicle are 7995×2350×3400mm respectively, and the wheelbase reaches 4500mm, which can ensure free access under different road conditions, not too large and limited by height, and also gives the owner greater possibility of loading. Simple mechanical structure, low price and practical loading space are the sharp tools for entrepreneurs to start their own businesses and make a profit.

Send Inquiry

Product Description

 Configuration table of electric power light truck project

 Based on the new light truck 8T wide body model variant

Item  Configuration name  Standar  Luxury
Remarks
Dimension parameters Cab width 2080
wheelbase 4500
Pattern Cab type 单排 Single row
Number of passengers allowed 3
Overall dimensions of the whole vehicle Van 7995×2350×3400
 Interior dimensions of cargo compartment Van Single row 6150×2300×2300
Weight parameters  Maximum total design mass 8000kg
Announcement Weight 7495kg
Power system Drive module Type  Permanent magnet synchronous motor + reducer
Drive motor  Rated power / Maximum power 70/130kW
Rated torque / Maximum torque 520/1510N.m
Motor protection class IP67
Motor cooling mode Water-cooling
Transmission speed ratio 3.68 - -
High pressure auxiliary drive Controller Three in one
Off-board charger OBC - -
Power battery Type Lithium iron phosphate
Battery capacity 162.28kWh
Upper power intake interface / - -
Degree of protection IP67
Gear selection and shift Type Electronic gear selector
Function With lock (with keyless start) -
Without lock (with key start) -
Voltage platform High voltage 600V
Low voltage 24V
Chassis Frame Type Straight stringer,Variable section,Ladder Type Channel Section
Longitudinal beam Texture of material 650L
Section size 214×70×5
Front suspension Type Parabolic Leaf with Shock Absorbers
Number of leaf springs 8 Leaf spring, multi leaf spring
Rear suspension Type  Parabolic Leaf with Shock Absorbers
Number of leaf springs 8+7  Leaf spring, multi leaf spring
 Front axle  Pattern  Pattern  Reverse Elliott I Beam
 Rated load 3000kg
 Maintenance free wheel end /
 Rear axle  Pattern  Pattern  Banjo,Fully floating
 Rated load 6000kg
Maintenance free wheel end /
 Wheel assembly  Specification 215/75 R17.5  215/75 R17.5 Steel wheel, equipped with drum brake Tubeless
 Steering system Pattern  Pattern  Electro hydraulic power(EHPS)
Steering machine  Circulating ball type
 Steering wheel Type (CC)
(ACC) Bilateral integrated multifunction (ACC) - -
Adjust Tilt / telescopic adjustable
 Driving brake system  Pattern  Pattern  Pneumatic braking
 Brake  Anterior drum posterior drum
ESC+EBS
 Parking brake system  Pattern  Spring energy storage
 Operating mechanism Manual control valve - -
EPB(autohold功能) EPB(autohold Function)
Body and accessories  Body color  White
 Green
 Red
 Blue
 Golden

 Sandwich glass /
 Rear windshield Tempered glass /
 Door window  Glass type  Tempered white glass
 Lifting type  Electric lifting  One key down on the driver's side One key down on the passenger's side
 Body  Exterior door handle  Same with body
 Roof ventilation / - -
Exterior decoration  Front bumper  The main body is in the same color as the body /
 Film A-pillar and side wall  Texture film - -
Shroud  Top Shroud  Short one
 Front grille Low end configuration grille  Without 360° camera -
 High end configuration grille  With 360° camera -
 Exterior accessories Exterior rearview mirror  Main lens adjustment mode  Driver's side  Manual adjustment -
 Electric regulation -
 Main lens adjustment mode Passenger side  Manual adjustment -
 Electric regulation -
Main lens heating and defrosting function / -
Interior rearview mirror /  Normal
 Vent / /
Interior Interior accessories  Get in the car handle  Driver's side
 Passenger side
 Safety handle  Driver's side - -
 Passenger side
 Sun visor  Driver's side
 Passenger side
 Overhead oddments tray  Driver's side
 Passenger side
 Rear oddments tray  Passenger side
Coat hook  Two,Behind the driver and passenger
 Ashtray / - -
Safety belt-Front seat Driver's side Three point force limiting without preload
 Three point belt pre tightening force limiting - -
Height adjustment
 Unbelted reminder
 Safety belt-Front seat Passenger side Three point force limiting without preload
Three point belt pre tightening force limiting - -
Height adjustment - -
Unbelted reminder
Safety belt-Front middle seat Two point type without preloa
Height adjustment - -
Unbelted reminder
Safety air bag  Driver's side - -
Passenger side - -
 Collision safety  Collision oil cut-off - -
 A-pillar lower guard  Left and right A pillar lower guard
Emergency power supply /
 Soft interior  Roof trim  Knitted fabric
 Non-woven fabric - -
 Rear wall interior trim  Knitted fabric
 Non-woven fabric - -
Door guard cladding Knitted fabric - -
PVC
 Carpet PVC
 Seat  Texture of material  Fabric + Leather
 Driver's seat adjustment 4 directions,Slide back and forth, non foldable and flat - -
4 directions,Slide back and forth, foldable and flat
Seat armrest
 Passenger seat adjustment Non adjustable - -
2 directions, Fold flat
 Middle backrest adjustment 2 directions, Fold flat, with cup holder andstorage box - -
 2 directions, Fold flat, without cup holder and storage box
Headrest  Non independent - -
 Independent
Lamps and lanterns  High and low beam (integrated)  Halogen band lens - -
LED
Height adjustable
 Auto on / off
  Daytime running LED
 Cornering lamp LED
Position lamp LED
Front fog lamp  Halogen - -
LED - -
  Side turn lamp  Halogen
LED - -
 Combined tail lamp  Halogen
 Clearance light (CAB)  Halogen
Door lamp  Driver side (Irradiate the upper pedal)
 Passenger side  (Irradiate the upper pedal)
 Reading lamp /
Wiper Type  Two arms in the same direction without skeleton
Electronic appliances  Electronic appliances Two arms in the same direction with skeleton - -
Combination instrument  Type  Normal - -
 7-inch LCD
 A/C  Type  Electric A/C
 Warm wind PTC Air PTC
PTC Plumbing PTC - -
 Ignition lock, door lock and accessories Start mode  Key start -
 Keyless start -
 Key  Folding key fob + mechanical key -
 Smart key + mechanical key -
 Door lock  Central control door lock
 Car entertainment /  MP3 + Radio - -
 Display   8-inch screen -
 12-inch screen -
Vehicle networking  Platform monitoring / - -
Intelligent networking  Electronic fence - -
 Remote locking - -
 Remote vehicle status query - -
Anti theft alarm status response - -
 Remote vehicle search - -
 Remote unlocking door lock - -
 Remote A/C - -
 Safety assistance  PDCParking Distance Control /
 Reversing image / -
 Blind spot monitoring / -
 Look around 360 / -
 Tachograph / - -
 Power interface of tachograph /
 Tachograph / - -
 Tire pressure monitor /
Reversing prompt /
Low speed alarm /
 Fatigue monitoring / - -
 Cruise control /
Load monitoring system / - -
Reminders  Door ajar reminder /
 Cab unlock reminder /
 Advanced driving assistance system LDW  Lane Departure Warning
FCW Front collision warning
AEB   Automatic emergency brake
ACC  Adaptive cruise - -
LKA  Driving lane keeping assistance - -
BCM Function  Automatic locking /
 Delayed closing of lamps /
 Internal lighting delay function /
 Internal lighting auto off function /
 Door anti-theft alarm /
Others  Mobile charger / - -
ETC / - -
Spare wheel device /
 Onboard tools / 心 Including warning triangle and reflective vest
●: standard   ○: option     —:


This is a new model electric light truck of New Longma. The 8T electric light truck has a very good power output whether driving at a low speed or climbing up a hill. The length, width and height of the vehicle are 7995×2350×3400mm respectively, and the wheelbase reaches 4500mm, which can ensure free access under different road conditions, not too large and limited by height, and also gives the owner greater possibility of loading. Simple mechanical structure, low price and practical loading space are the sharp tools for entrepreneurs to start their own businesses and make a profit.
