Electric Mini Truck N55

KEYTON electric mini truck, has a very good power output whether driving at a low speed or climbing up a hill. The length, width and height of the vehicle are 4845 / 1610 / 1920mm respectively, and the wheelbase reaches 3050mm, which can ensure free access under different road conditions, not too large and limited by height, and also gives the owner greater possibility of loading. Simple mechanical structure, low price and practical loading space are the sharp tools for entrepreneurs to start their own businesses and make a profit.Welcome to buy Electric Mini Truck N55 from us.

Send Inquiry

Product Description

1.Introduction of Electric Mini Truck N55

KEYTON electric mini truck, has a very good power output whether driving at a low speed or climbing up a hill. The length, width and height of the vehicle are 4845 / 1610 / 1920mm respectively, and the wheelbase reaches 3050mm, which can ensure free access under different road conditions, not too large and limited by height, and also gives the owner greater possibility of loading. Simple mechanical structure, low price and practical loading space are the sharp tools for entrepreneurs to start their own businesses and make a profit.





2.Basic parameters of the whole vehicle

Project

Electric Mini Truck

Main configuration

CATL battery

Number of seats (including driver)

2

Dimension

Size

L*W*H mm

4845*1610*1920,1935

Cargo space

L*W*H mm

3015*1530*370

Wheelbase  mm

3050

Tread

Front  mm

1386

Rear  mm

1408

Weight

Curb weight,Kg

1355

Total weight,Kg

2510

Rated load mass,Kg

1155

Pass parameter

Minimum ground clearance,mm

125

Front suspension,mm

545

Rear suspension,mm

1255

Approach angle,(°)

31

Departure angle,(°)

22

Minimum turning diameter,m

11.9

Driving range

(km)

Working condition method

300

Steering gear

Type

Rack and pinion type (with power assist)

Rear axle

Main reducer

Two stage cylindrical gear speed ratio 8.952

Differential mechanism

Straight planet bevel gear

Driving system

Front suspension

Spiral spring McPherson type independent suspension

Rear suspension

Leaf spring non independent suspension

Tire specification(F/R)

175/75R14C;185R14C(Rear)

Braking system



Type

Double circuit X-type hydraulic brake

Brake

Front disk rear drum

Parking brake

Mechanical cable type applied to rear wheel brake











Driving motor

Quantity, set / vehicle

1

Type

Permanent magnet synchronous motor

Model

TZ180XSIN101

Phase number m

3

Rated torque,N·m

90

2min maximum torque

2Min,N·m

220

Rated power,kW

30

2min maximum power,kW

60

Rated speed,r/min

3183

Rated efficiency,%

96.5

Motor controller

Model

KTZ33X26S330L

Rated voltage,V

336

Electrical system

Auxiliary battery

12V

Power battery

Battery type

Lithium iron phosphate battery

Rated voltage,V

334.88

Capacity C3,A·h

125

Service life

5 years or 200000 km

Energy density(W.h/kg)

137.6

Charger (AC / DC)

Input voltage,VAC

220

Maximum output current,A

3.3kw charger ≤ 10

Maximum charging time,h

3.3kw charger ≤ 12

Lighting, signal

Headlamp, front and rear turn light, front and rear position light, brake light, rear fog light, reversing light, license plate light, combination instrument, interior light, indicator light, horn, hazard warning light, etc

Air conditioning

Air conditioning

Electric compressor Rated power,W

950

Refrigerating capacity,W

1850

Cryogen

R134a

Heater

Rated fan power,W

175



Calorific value,W

2000

◆ Chassis and brake system

Front McPherson independent suspension

S

Rear leaf spring independent suspension

S

Front disc and rear drum hydraulic brake

S

ABS+EBD

S

EPS

S

vacuum booster

S

◆ Electrical equipment

Radio player

S

USB

O

Reverse warning tone

-

parking sensor

S

Reversing image

O

Driver's airbag

-

Passenger airbag

-

3.3kw Charge

S

6.6kw Charge

O

Low speed tone assembly

S

Charging socket and harness assembly (slow charging)

S

Charging socket and harness assembly (fast charging)

S

◆ Body accessories

Driver's power window

S

Front passenger power window

O

Manual co driver's window

S

Central locking

S

Remote key

O

Partition of passenger and freight area

-

◆ Interior and exterior decoration

Left and right sun visors

O

Hub trim cover

O

◆ Air conditioning system

Electric heating system

S

Electric air conditioning system

S

◆ On board tools

Fire Extinguisher

O

On board tool assembly

S

Warning triangle

S

Jack assembly

S

Reflective Vest

-

Full size spare tire

S

Remarks: "s" standard configuration, "O" optional configuration, "-" not assembled

Note: This information is only for reference,Newlongma has final explanation right.




3.Product Qualification

KEYTON EV50 Electric Minivan passes the following quality management certifications:

M70 Manual Transmission Minivan




4.FAQ

1.What is the selling point of your company?

Our FJ Group is the JV partner with Mercedes-Benz, producing V Class in China. That’s why all our products standard is even higher than other Chinese brands.



2.How many countries have you ever exported to?

We have exported to Bolivia, Myanmar, Philippines, Egypt, Nigeria, about 20 countries.



3.What is your biggest overseas market?

We have sold more than 5,000 units to Bolivia since 2014, and the altitude of that country is about 3,000 meters. Which means the vehicles is running well in the tough area.



4.What about the WARRANTY?

We are offering 2 years or 60,000 kms, whichever comes first.



5.What about the delivery time?

45 days since down payment.
